ChemicalBook
English   Japanese   Germany   Korea

939-23-1

4-苯基吡啶(939-23-1)紅外圖譜(IR1)

產(chǎn)品名稱:4-苯基吡啶

CAS:939-23-1

分子式:C11H9N

分子量: 155.2

InChI:InChI=1S/C11H9N/c1-2-4-10(5-3-1)11-6-8-12-9-7-11/h1-9H

InChIKey: JVZRCNQLWOELDU-UHFFFAOYSA-N

Smiles:C1=NC=CC(C2=CC=CC=C2)=C1

  • 圖譜
    Mass

    MS-NW-8651
4-phenylpyridine
C11H9N              (Mass of molecular ion:    155)


       Source Temperature: 250 °C
   Sample Temperature: 140 °C
   Reservoir, 75 eV


          39.0       1.9
      50.0       4.1
      51.0       9.3
      52.0       2.5
      62.0       1.5
      63.0       4.7
      64.0       6.2
      74.0       2.7
      75.0       3.1
      76.0       3.9
      77.0       6.2
      77.5       2.6
      78.0       2.3
      87.0       1.0
      89.0       1.3
     101.0       2.2
     102.0       8.2
     103.0       1.2
     115.0       8.9
     116.0       1.6
     126.0       3.7
     127.0      11.2
     128.0      11.8
     129.0       2.5
     140.0       4.1
     153.0       2.1
     154.0      31.0
     155.0     100.0
     156.0      12.4

  • 圖譜

in CDCl3

  • 圖譜

KBr disc

  • 圖譜

  • 圖譜

PHOTOLYSIS, IN 2-PROPANOL/ACETONE

  • 圖譜

×
