Mass

MS-IW-2675
1,5-dinitronaphthalene
C10H6N2O4           (Mass of molecular ion:    218)

   Source Temperature: 140 °C
   Sample Temperature: 110 °C
   Direct, 75 eV

      28.0       2.2
      30.0       4.5
      38.0       1.0
      39.0       3.9
      50.0       8.0
      51.0       6.3
      52.0       2.5
      55.0       1.1
      61.0       2.3
      62.0       6.6
      63.0      15.3
      64.0       3.1
      65.0       1.2
      73.0       1.0
      74.0      17.9
      75.0      23.7
      76.0      20.5
      77.0       8.4
      78.0       1.4
      85.0       1.4
      86.0       5.1
      87.0       9.3
      88.0      12.6
      89.0      20.8
      90.0       7.7
      91.0       6.0
      92.0       1.3
      98.0       6.2
      99.0       8.0
     100.0       8.1
     101.0       8.6
     102.0      20.7
     103.0       2.6
     104.0      10.8
     105.0       5.1
     113.0      15.8
     114.0      73.1
     115.0       9.0
     116.0      15.5
     117.0       3.4
     118.0       3.7
     119.0      25.2
     120.0       5.3
     122.0       1.6
     125.0       6.3
     126.0      56.3
     127.0       7.9
     128.0       3.8
     129.0       3.2
     130.0      11.9
     131.0       1.5
     132.0       9.2
     133.0       1.5
     141.0       6.9
     142.0      10.7
     143.0       1.7
     144.0       2.9
     145.0       1.0
     146.0       2.3
     156.0       2.0
     158.0      13.3
     159.0       2.8
     160.0       1.7
     172.0       2.6
     188.0       2.4
     202.0       1.1
     218.0     100.0
     219.0      11.9
     220.0       1.5
