2-乙氧基芐胺(37806-29-4)紅外圖譜(IR1)

產(chǎn)品名稱:2-乙氧基芐胺

CAS:37806-29-4

分子式:C9H13NO

分子量: 151.21

Mass

MS-IW-0747
o-ethoxybenzylamine
C9H13NO             (Mass of molecular ion:    151)

   Source Temperature: 200 °C
   Sample Temperature: 160 °C
   Reservoir, 75 eV

      27.0       3.7
      28.0       9.0
      29.0       3.7
      30.0      11.9
      38.0       1.1
      39.0       6.5
      40.0       1.3
      41.0       3.0
      43.0       1.2
      44.0      17.4
      50.0       2.4
      51.0       8.3
      52.0       3.2
      53.0       2.2
      54.0       1.4
      55.0       1.4
      63.0       3.0
      64.0       1.7
      65.0       6.9
      66.0       6.4
      67.0       4.0
      75.0       1.0
      76.0       1.7
      77.0      35.7
      78.0      23.0
      79.0      11.9
      80.0       1.4
      89.0       1.8
      90.0       2.5
      91.0      15.0
      92.0       3.1
      93.0       4.9
      94.0      15.0
      95.0      38.7
      96.0       2.8
     102.0       1.7
     103.0       1.2
     104.0      17.1
     105.0      14.1
     106.0      38.7
     107.0      22.3
     108.0       3.2
     115.0       1.9
     116.0       1.5
     117.0       3.3
     119.0      22.7
     120.0       6.6
     121.0       5.9
     122.0     100.0
     123.0       9.7
     132.0       1.4
     133.0      27.7
     134.0      82.3
     135.0      21.2
     136.0      23.2
     137.0       2.1
     148.0      10.9
     149.0       1.2
     150.0      50.1
     151.0      63.0
     152.0       7.2
     268.0       1.4
     283.0       1.0

90 MHz in CDCl3

¹H NMR	89.56 MHz
C₉ H₁₃ N O	0.05 ml : 0.5 ml CDCl₃
o-ethoxybenzylamine

    Assign.     Shift(ppm)

      A             7.15
      B             7.14
      C             6.84
      D             6.80
      E             4.011
      F             3.789
      G             1.76
      J             1.402

     COMFIRMED BY LAOCN CALCULATION

     Hz     ppm     Int.

    651.94   7.280     67
    650.13   7.260    138
    647.38   7.229    107
    646.81   7.223    111
    645.00   7.202    187
    642.56   7.175    170
    640.31   7.150    181
    638.38   7.128    221
    636.25   7.105    214
    634.38   7.084     76
    622.31   6.949    132
    621.06   6.935    184
    614.50   6.862    260
    613.25   6.848    318
    610.50   6.817     71
    607.81   6.787    110
    605.81   6.765    145
    604.19   6.747    100
    370.13   4.133    130
    363.13   4.055    413
    356.13   3.977    439
    351.25   3.922     48
    349.19   3.899    162
    339.38   3.790    842
    158.19   1.767    525
    132.38   1.479    515
    125.44   1.401   1000
    118.44   1.323    464

in CDCl3
