2268-05-5

2,6-二氯氟苯(2268-05-5)核磁圖(13CNMR)

產(chǎn)品名稱:2,6-二氯氟苯

CAS:2268-05-5

分子式:C6H3Cl2F

分子量: 164.99

InChI:InChI=1S/C6H3Cl2F/c7-4-2-1-3-5(8)6(4)9/h1-3H

InChIKey: JORVCRLRRRRLFI-UHFFFAOYSA-N

Smiles:C1(Cl)=CC=CC(Cl)=C1F

  • 圖譜
    Mass

    MS-IW-9271
1,3-dichloro-2-fluorobenzene
C6H3Cl2F            (Mass of molecular ion:    164)


       Source Temperature: 220 °C
   Sample Temperature: 150 °C
   Reservoir, 75 eV


          31.0       1.5
      37.0       1.7
      49.0       1.0
      50.0       3.1
      61.0       2.1
      62.0       1.7
      63.0       1.9
      64.0       4.6
      65.0       1.4
      68.0       5.0
      69.0       1.4
      73.0       2.1
      74.0       5.2
      75.0       1.7
      82.0       6.2
      83.0       4.1
      84.0       2.2
      92.0       2.4
      93.0       9.0
      94.0       5.3
     103.0       1.1
     104.0       1.1
     109.0       6.6
     111.0       2.1
     128.0       4.8
     129.0      34.7
     130.0       3.9
     131.0      11.2
     164.0     100.0
     165.0       6.9
     166.0      63.7
     167.0       4.3
     168.0      10.2

400 MHz in CDCl3

  • 圖譜

    1H NMR 399.65 MHz
    C6 H3 Cl2 F 0.040 g : 0.5 ml CDCl3
    1,3-dichloro-2-fluorobenzene
    ChemicalStructure
        Assign.     Shift(ppm)

      A             7.303
      B             7.028


         Hz     ppm     Int.


       2926.51   7.323    808
   2919.92   7.307    846
   2918.33   7.303   1000
   2911.87   7.287    952
   2905.15   7.270     25
   2817.26   7.050    318
   2815.67   7.046    313
   2809.45   7.030    388
   2808.84   7.029    347
   2807.74   7.026    400
   2801.03   7.009    244
   2799.44   7.005    236

in CDCl3

  • 圖譜

KBr disc

  • 圖譜

nujol mull

  • 圖譜

  • 圖譜

×
