N-乙基正丙胺(20193-20-8)Raman光譜

產(chǎn)品名稱:N-乙基正丙胺

CAS:20193-20-8

分子式:C5H13N

分子量: 87.16

InChI:InChI=1S/C5H13N/c1-3-5-6-4-2/h6H,3-5H2,1-2H3

InChIKey: XCVNDBIXFPGMIW-UHFFFAOYSA-N

Smiles:C(NCC)CC

Mass

MS-NW-8338
N-ethylpropylamine
C5H13N              (Mass of molecular ion:     87)

   Source Temperature: 250 °C
   Sample Temperature: 140 °C
   Reservoir, 75 eV

      15.0       1.3
      18.0       1.7
      27.0       6.9
      28.0       8.2
      29.0       6.7
      30.0      59.9
      39.0       2.4
      41.0       7.1
      42.0       4.5
      43.0       6.8
      44.0       9.2
      56.0       2.9
      58.0     100.0
      59.0       3.8
      70.0       1.3
      72.0       6.2
      86.0       3.3
      87.0      10.6

90 MHz in CDCl3

¹H NMR	89.56 MHz
C₅ H₁₃ N	0.04 ml : 0.5 ml CDCl₃
N-ethylpropylamine

    Assign.     Shift(ppm)

      A             2.65
      B             2.57
      C             1.50
      D             1.111
      E             1.08
      F             0.93

     Hz     ppm     Int.

    248.38   2.774     97
    247.94   2.769     93
    240.94   2.691    423
    238.38   2.662    199
    238.00   2.658    193
    233.75   2.610    493
    231.25   2.583    405
    230.06   2.569    216
    227.06   2.536    151
    226.69   2.532    149
    223.94   2.501    277
    146.06   1.631    119
    140.06   1.564     98
    139.13   1.554    130
    138.25   1.544    156
    132.31   1.478    142
    131.19   1.465    197
    124.25   1.388    134
    106.31   1.188    454
     99.31   1.109   1000
     96.56   1.079    190
     92.06   1.028    379
     90.00   1.005    203
     89.25   0.997    359
     88.56   0.989    259
     82.44   0.921    560
     75.63   0.845    101
     74.75   0.835    190
     73.50   0.821    117

in CDCl3
