ChemicalBook CAS DataBase List Boc-NH-PEG2-CH2COOH

Boc-NH-PEG2-CH2COOH synthesis

9synthesis methods

Product Name:Boc-NH-PEG2-CH2COOH
CAS Number:108466-89-3
Molecular formula:C11H21NO6
Molecular Weight:263.29

To a stirred solution of 2-(2-(2-Aminoethoxy)ethoxy)acetic acid (5.0 g, 30.6 mmol) in 1,4-Dioxane (50 mL), Sodium carbonate (8.12 g, 76.5 mmol, dissolved in 10 mL water) and (Boc)2O (9.98 mL, 45.7 mmol) were added and stirred at room temperature for 12 h. The progress of the reaction was monitored by TLC. The reaction mass was partitioned between diethyl ether and water. Then, the aqueous layer was made acidic (pH = 3) by 3N HC1 solution and was extracted with DCM (2 x 200 mL). The organic layer was washed with water, and brine, dried over Na2504 and evaporated under reduced pressure to yield 50 g of pure Boc-NH-PEG2-CH2COOH (Yield:62.1 per cent).

24424-99-5 Synthesis

24424-99-5
859 suppliers
$13.50/25G

105-36-2 Synthesis

105-36-2
355 suppliers
$5.00/5 g

929-06-6 Synthesis

929-06-6
294 suppliers
$10.00/1g

108466-89-3
176 suppliers
$9.00/100mg

Yield:108466-89-3 82%

Reaction Conditions:

Stage #1:di-tert-butyl dicarbonate;2-(2-Aminoethoxy)ethanol in ethanol at 20; for 2 h;Cooling with ice;
Stage #2: with sodium hydride in tetrahydrofuran at 0 - 10; for 0.5 h;
Stage #3:ethyl bromoacetateFurther stages;

Steps:

1-1 Example 1-1:
Using 2-(2-aminoethoxy)ethanol 2 as the starting material (100 mmol, 10.5 g), dissolve 150 mL of ethanol solution, add di-tert-butyl dicarbonate (100 mmol, 23 mL) dropwise under ice bath conditions, and remove the ice Bath, react at room temperature for 2h, distill off the ethanol solvent under reduced pressure; THF is redissolved, add NaH (1.2-1.5eq) at 0 ~ -10 °C, keep this temperature and stir for half an hour, and ethyl bromoacetate 3 (1.2-1.5eq ) Slowly drop the reaction solution, remove the ice bath after the dropwise addition, and stir at room temperature overnight. MeOH was added to the reaction system to make MeOH:THF=1:1, the reaction solution was yellow and clear, and solid NaOH (1-2.2eq) was weighed into the reaction solution, heated to reflux, and reacted for 2h. After the reaction was completed, the solvent was distilled off under reduced pressure. The residue was redissolved with water, extracted twice with ethyl acetate, and the aqueous layer was collected, adjusted to pH 1~3, extracted twice with ethyl acetate, and the organic layer was collected and distilled under reduced pressure to obtain yellow Oily liquid 4. The yield was 82%.

References:

Zhejiang University of Technology;Zhang Fengzhi;Yang Bin CN111269137, 2020, A Location in patent:Paragraph 0077-0079; 072
